Benchtop Units for Coating Thickness Measurement
FISCHERSCOPE® MMS® PC2
|
Features
- Coating thickness measurement and material testing with just one instrument!
- Compact and extremely versatile desktop multi-function measuring system with data
archiving and measurement data processing capabilities.
- User-friendly operation with large, high-resolution color LCD touch screen. Windows CE® based.
- Many different plug-in testing modules allow numerous instrument configurations to meet the needs of the user.
The modular design allows the upgrading of the instrument at any time. Similar or different modules can be
installed depending on the applications.
- Different physical measurement principles are applied by the plug-in modules BETASCOPE®,
SIGMASCOPE®, PHASCOPE®, DUPLEX, NICKELSCOPE®,
SR-SCOPE® and PERMASCOPE®, Details see brochure.
- Multi-channel measurements at up to 8 measurement locations
- A great variety of probes for different test piece geometries and measuring ranges are available.
- Delivery with PC software FISCHER DataCenter with the following functionality: Transferring
and archiving measurement data, comprehensive statistical and graphical evaluations, easy creation
and printing of inspection reports
|
|
|
Premium Benchtop unit for universal coating thickness measurement and material testing,
with color touchscreen, individual configuration and various interfaces
|
|
More information:
|
Typical fields of applications
- Electroplating and paint manufacturing on steel. Anodized coatings on aluminum (PERMASCOPE®)
- Nano coatings (Antifingerprints), Solar cell coatings (CdTe/ glass), Gold coatings on contacts,
tinlead alloy coatings on solder pads and traces, photo resist coatings, oil and wax coatings (BETASCOPE®).
- Surface copper cladding thickness and copper plating thickness in
through-holes (SIGMASCOPE®/ PHASCOPE®) on pc-boards.
- Copper thickness on laminates and multilayers without any influence from
the copper coating on the opposite side (SR-SCOPE®) in pc-board production
- Thickness of solder resist on copper (PERMASCOPE®) in pc-board production
- Graphite coatings on the surface of pistons or corrosion resistance
coatings on brake discs (PERMASCOPE®) in automotive industry
- Ferruginous coatings on the piston surfaces (NICKELSCOPE®) in Automotive industry
- Ferrite content in austenitic or duplex steel (PERMASCOPE®).
- Electrical conductivity of non-magnetic metals like copper, aluminum, titanium (SIGMASCOPE®)
|
